We Sell Manufacturer, Trade, Import, Supply R.O pure water treatment machine 5000Liter water filter system reverse osmosis plant Germany

R.O pure water treatment machine 5000Liter water filter system reverse osmosis plant Description

High Quality SS 304 Small RO Water Treatment Plant , 5000LPH GPD RO Water Purifier Machine

• ? RAW WATER STORAGE TANK ()

• ? RAW WATER PUMP

• The Raw Water Would be Pumped To The MSF, ACF, And MCF By Means of a Raw Water

• Pump. This Pump Will Create the Minimum Head Required For The Multi-Grade Filter Pump

• To Boost The Water.

• ? MULTIGRADE SAND FILTER

• The Raw Water From Its Source Will Is Directly Passed Through The MSF to Remove

• Suspended Solids From The Same. The MultiGrade Sand Filter Will Be Designed For a Filtration

• Velocity of 19-20 m/hr for Efficient Filtration

• ? ACTIVATED CARBON FILTER

• The Raw Water From Its Source Will Be Directly Passed Throught The ACF to remove Chlorine,

• Color & Odor From Raw Water. The Charcol Filter Will Be Designed For a Filtration Velocity of

• 19-20 m/hr For Efficient Filtration.

? ANTISCALENT DOSING SYSTEM

It is Processed to Dose Special Food Grade Antiscalent in the Feed Prior to the Cartridge Filter

for RO System to prevent saturation of various organic salts especially Silica on RO membrane

surface on concentration.

The features of this Antiscalent are:

Prevent organic and inorganic fouling of the Reverse Osmosis system.

? Take care of high incoming silica and bicarbonate

load in the feed to the RO thus

Reducing Scaling of the RO Pressure Tubes

? MICRON CARTRIDGE FILTER (MCF)
A MCF is provided to remove fine suspended solids, which may escape from upstream units. 5
Micron cartridge filter is provided which will remove fine suspended solids up to 5 micron,
which if not trapped may clog the RO membrane. This would also eliminate problems in the
high-pressure pumps due to presence of particulate matter.

? REVERSE OSMOSIS SYSTEMRO will serve the purpose of Reducing TDS 1000 to around < 100ppm. The RO unit shall have a
conductivity meter at the outlet to monitor the performance

? STORAGE OF RO TREATED WATER

Remove back pressure in R.O. Membrane elements. It is only storage of the treated Water

? FINE POLISHING FILTERATION

To filter the water from 1 micron to achieve the crystal clear filtered water.

? UV SYSTEM

kill the bacteria from fine water

SCOPE OF EXCLUSION:

? Foundation for Equipment & Civil Works.

? Power, Water & Electrical works.

? Raw Water Storage.

? SOURCE OF WATER:

? R.O. plant is designed based on 1500 PPM TDS&300 PPM raw water hardness

RAW WATER FEEDING PUMP:

Type : Centrifugal

Max. Flow : 6.0 m3/hr.

Working flow : 5.5 m3/hr.

Working pressure : 2 kg/cm2

M.O.C. : C.I.

Power : 2 HP.

Make : Kirloskar.

Nos. Offered : One No

PRESSURE SAND FILTER:
